Description

Fort Vale Bottom Discharge Assembly 3″ 45° Uniflow

Specification
80mm / 45°
Inlet connection
Nominal size/body angle
Flanged: 8 x 14mm holes equi-spaced on a 178mm PCD
Outlet connection
3″ BSP spigot flange with cap
Properties
Cleanflow footvalve with integral butterfly valve
Materials
Seating area: Superseat (alloy 625)
Contact parts: 316 stainless steel
Footvalve main seal: Fortyt
Butterfly valve main seal: PTFE
Cap seal: PTFE
Weight: 13.0 Kg
Design Pressure (MAWP): 4 Bar
Test Pressure: 6 Bar
Design Temperature min: -40°C
Design Temperature max: 200°C
BS EN14432 / BS EN14433
